QMA MALE RIGHT ANGLE TO N FEMALE; TFT-402LF; PIM TESTED; 39″
P2RFC-2406-39
Description
Plenum rated, low PIM coaxial cable assemblies using ultra flexible Times Microwave TFT™-402-LF cable
• IM3 4.3-10 (only):≤-160dBc@ 700MHz & 1900Mhz
IM3 (all others): ≤-155dBc@ 700MHz & 1900Mhz
• 3rd Intermodulation Test: Two +43dBm carriers
• Cable assemblies are 100% PIM tested
• Low Passive Intermodulation Distortion (PIM)
• Operating frequency: up to 3 GHz
• Highly flexible flat braided outer conductor
• Cost effective alternative to .141 inch size semi-flexible solder braided cables
• UL910 plenum rated, satisfying building code requirements
• Highly flexible for ease of installation
Cables are 100% tested for static and dynamic PIM with the results available online via PIM Tracker™.
Additional information
| Connector 1 | |
|---|---|
| Connector 1 Series | |
| Connector 1 Gender | |
| Connector 2 | |
| Connector 2 Series | |
| Connector 2 Gender | |
| Assembly Length | |
| Cable Part Number | |
| Low PIM Rated | |
| PIM Test | • IM3 4.3-10 (only):≤-160dBc@ 700MHz & 1900Mhz • IM3 (all others): ≤-155dBc@ 700MHz & 1900Mhz |
Connector Drawing
